Engine Timing Belt 13568-09041 163S8M27 for Toyota Camry Avensis Celica Land Cruiser HDJ100 HZB50

Name: Engine Timing Belt 13568-09041 163S8M27 for Toyota Camry Avensis Celica Land Cruiser HDJ100 HZB50
SKU: C1688-915130953041
Availability: InStock

$10.07

Shop the high-durability 13568-09041 Timing Belt for Toyota Camry, Land Cruiser HDJ100 & Coaster. Made from heat-resistant CR rubber for 1HD/1HZ 4.2L engines.

999 in stock

Full description

SKU: C1688-915130953041 Category: Timing Belt Tags: 13568-09041, 163S8M27 belt, Camry timing replacement, engine synchronization belt, Land Cruiser 4.2L belt, Toyota timing belt

Description

Key Selling Points

OE-Equivalent Fitment: Specifically engineered to match OEM specifications 13568-09041 and 163S8M27, ensuring a perfect fit for Toyota Avensis, Camry, and Land Cruiser models.
Premium CR Material: Manufactured from high-grade Chloroprene Rubber (CR) for superior resistance to heat (up to 120°C), oil, and wear, significantly extending the service life of your engine's timing system.
Precision Tooth Profile: Features a precision-molded tooth design for quiet operation and efficient power transmission, reducing vibration and preventing slippage under high-load conditions.
Comprehensive Application: Versatile compatibility across a wide range of Toyota engines including 1HD 4.2L and 1H-Z 4.2L units used in Land Cruisers and Coaster buses.
Reliable Synchronization: Ensures exact synchronization between the crankshaft and camshaft for optimal valve timing, maximizing engine performance and fuel efficiency.

Technical Specifications

Part Number	13568-09041 / 13568-74020 / 90916-02452
Material	Chloroprene Rubber (CR)
Tooth Configuration	163S8M27
Heat Resistance	Up to 120°C
Compatible Engines	1HD 4.2L, 1H-Z 4.2L (1990-2007)

FAQ Q&A

Q: Does this belt fit the 4.2L diesel engine found in the Land Cruiser HDJ100?

A: Yes, this belt is specifically compatible with the 1HD 4.2L and 1H-Z 4.2L engines used in the Land Cruiser HDJ100, HZJ78, and HZJ79 series.

Q: How often should I replace this timing belt?

A: While the CR material is highly durable, it is recommended to replace the timing belt every 60,000 to 100,000 miles (approx. 100,000 km) as per your Toyota service manual to prevent engine damage.

Q: Is this a V-belt or a toothed timing belt?

A: This is a toothed timing belt (163S8M27) designed for engine synchronization, though the listing cross-references related auxiliary V-belts for the same vehicle series.
